HDPE Dam Liners
100% impervious virgin high-density polyethylene sheets with dual-track hot wedge thermal welding for multi-season agricultural reservoirs.
*Prices exclude localized transport outside Nairobi. On-site installation and testing included for turnkey systems.
Agronomic Overview & Specifications
Technical Data & Material Standards
Precision manufacturing parameters tested for prolonged tropical UV exposure and mechanical stress.
What's Included in the Package
Full bill of quantities delivered to your farm site:
- Custom factory pre-cutting to match excavated pond geometry with anchor allowances
- Mobilization of certified thermal hot-wedge welding technicians to your farm
- High-pressure pneumatic channel testing on every welded joint before water filling
- Non-woven geotextile underlay cushion placement (optional for stony soils)
- Anchor trench excavation advisory (50cm × 50cm peripheral perimeter trench)
- Inlet and overflow pipe boot seals preventing water backflow erosion
- Symnet manufacturer quality certificate and warranty document
Ideal Crops & Varieties
Agronomist-recommended crops for maximum return on investment:
- •Gravity Irrigation for All Horticultural Crops (Tomatoes, Onions, Watermelons)
- •Commercial Tilapia & Catfish Aquaculture Farming
- •Livestock Drinking Water Reservoirs for Dairy & Beef in ASAL Counties
- •Off-Grid Avocado & Fruit Tree Drip Reservoir Storage
Available Dimensions, Capacities & Rates
Select the size suited to your acreage, water volume, or commercial market targets. Custom scales fabricated on request.
0.5mm HDPE Geomembrane
Custom cut (Roll width 7.0m / 8.0m)
Small fish ponds, residential irrigation pans, soft clay soils with no stones.
0.75mm HDPE Geomembrane
Custom cut (Roll width 7.0m / 8.0m)
Our most popular commercial farm liner. Recommended for stony ground and large reservoirs.
1.0mm HDPE Geomembrane
Custom cut (Roll width 7.0m / 8.0m)
Large public dams, rocky terrain, industrial effluent reservoirs, and harsh ASAL zones.
300 GSM Geotextile Underlay
Roll width 4.0m / 6.0m
Installed beneath HDPE liner on gravelly, rocky, or root-infested ground.
Professional On-Farm Installation Workflow
Every Symnet installation follows a strict 4-stage engineering protocol to ensure long-term structural integrity and zero operational failure.
Excavation & Slope Shaping
Pond slopes should be excavated at a 1:1 or 1:1.5 gradient. Remove all sharp stones, roots, and debris, followed by compacting the subgrade.
Anchor Trench Digging
Dig a 50cm wide by 50cm deep anchor trench around the entire perimeter, set back 1 meter from the pond crest.
Geotextile & Liner Deployment
Roll out geotextile fleece, unroll HDPE panels into the pond basin, align overlap seams with 10cm–15cm lap margin.
Thermal Welding & Backfilling
Fuse seams with hot wedge machine, perform air channel spark pressure test, lay liner edges into anchor trench and backfill with soil.
Frequently Asked Questions: HDPE Dam Liners
Key insights on maintenance, warranties, and agronomic management.
